Parameters
| PV Parameters | |
| Max Pv Power | 65KW |
| MPPT QTY | 4 |
| Max Pv Current | 55*4 |
| Max Pv VOC | 1000V |
| MPPT Operating Power | 150-850V |
| DC Parameters | |
| Battery Cell Capacity | 64V280AH(20S1P) |
| Material | LiFePO4 |
| Cycle Life | |
| Battery Pack Configuration | 160S1P |
| DC Working Voltage Range | 480-576V |
| Rated Voltage | 512V |
| Rated Energy | 143.36kWh |
| Charging & Discharge Rate | 0.5C |
| AC Parameters | |
| Rated Output Power | 50KW |
| Max Output Power | 55KW |
| Max AC Charge Power | 55KW |
| Rated On-Grid Voltage | 400AC |
| Output Voltage Frequency | 50/60Hz; 3L/N/PE 220/380, 230/400Vac |
| Grid Connection | Three phase |
| SYSTEM PARAMETERS | |
| Size (W*D*H) | L1180*D1020*H2274 |
| Net Weight | 1800KG |
| Protection Grade | IP54 |
| Anticorrosion Grade | C3(Optional upgrade to C4/C5) |
| Working Temperature | -20°C ~+55°C |
| Working Humidity | 0~95% No Condensation |
| Working Altitude | <3000m |
| Cooling Method | Industrial Grade Air Conditioner |
| Noise Emission | Standby <50 (dB), Operating <70 (dB) |
| COMMUNICATION PARAMETERS | |
| Communication Port | CAN/ RS485 /232 |
| Communication Protocol | BMS(Modbus Rtu ) |
| CERTIFICATION | IEC 61727,IEC 62116,CEI 0-21,EN 50549,NRS 097,RD 140, UNE 217002,OVE-Richtlinie R25,G99,VDE-AR-N 4105 |
Features
Our system charges when electricity is cheap and discharges when it's expensive, significantly lowering your power costs. It also stores excess solar energy, boosting green energy self-consumption to accelerate your ROI.
The system switches over in milliseconds during outages, ensuring continuous production. It also stabilizes voltage to protect sensitive equipment and extend its lifespan.
Our cloud platform allows for real-time monitoring of the system. It operates automatically, requiring no manual intervention and enabling true hands-off operation.
Its modular design lets you scale capacity as needed, lowering your initial investment. The compact design also makes installation simple and space-efficient.
Applications
Commercial and industrial energy storage systems help factories, commercial buildings, and charging stations reduce costs, improve efficiency, and ensure power reliability by enabling peak shaving, providing backup power, and optimizing self-consumption of solar energy.
