Lead Acid Replacement Battery 24V 100AH 150AH 200AH 230AH

  • Lawn and garden tools
  • Parking lots
  • Garages and warehouse
  • Home use cars
  • Marine backup power supply
  • Photovoltaic 12V 24V 48V off grid applications
  • Telecom base station energy storage
  • Electric wheelchairs and scooters
  • Golf cart parking air conditioning

Product Specifications

MODEL EBL-24-100 EBL-24-150 EBL-24-200 EBL-24-230
Cell Lithium iron phosphate
Nominal voltage 25.6V 25.6V 25.6V 25.6V
Nominal capacity 100Ah 150Ah 200Ah 250Ah
Energy 2560Wh 3840Wh 5120Wh 5888Wh
Cycle life ≥6000 cycles @80%DOD @25℃
Series parallel mode 8S1P 8S1P 8S2P 8S1P
Operating temperature Charging O~+55 |Humidity 15%~75%|Storage 10~+50
Protection Electronic circuit breaker,BMS voltage protection,current limiting
Water dust resistance IP65
Net Weight(kg) 19.1 25.8 37.2 40
Size(mm) 502*186*243 502*186*243 523*269*218 520*269*220
Function Bluetooth,Led Screen (optional)
